JOPOWER 36 inch LED Rear Strobe LED Chase Light Bar for ATV UTV Offroad

The JOPOWER 36 Inch LED Rear Strobe Chase Light Bar is designed for ATVs and UTVs, offering bright strobe lighting for enhanced visibility and safety during off-road rides.
Brand
JOPOWER
Pre-Programmed Modes
27 modes
Pre-programmed features
include strobe, scroll, flash
LED Colors
Red, White, Blue, Green And Amber
Use
User Defined Programming And Usage
Operating Temperature
-40F to 158F, Integrated Thermal Management
SAE J575 Compliant
Shock/Vibration
Material
High Grade Aluminum Alloy Housing And Heat Sink
Waterproof
IP68, Dust/Water Ingress
  • JOPOWER 36 inch LED Rear Strobe LED Chase Light Bar for ATV UTV Offroad
  • JOPOWER 36 inch LED Rear Strobe LED Chase Light Bar for ATV UTV Offroad
  • JOPOWER 36 inch LED Rear Strobe LED Chase Light Bar for ATV UTV Offroad
  • JOPOWER 36 inch LED Rear Strobe LED Chase Light Bar for ATV UTV Offroad
  • JOPOWER 36 inch LED Rear Strobe LED Chase Light Bar for ATV UTV Offroad
  • JOPOWER 36 inch LED Rear Strobe LED Chase Light Bar for ATV UTV Offroad
  • JOPOWER 36 inch LED Rear Strobe LED Chase Light Bar for ATV UTV Offroad
  • JOPOWER 36 inch LED Rear Strobe LED Chase Light Bar for ATV UTV Offroad

Description

Rear Safety in Off-Road Use

Most builds start with an off road led light bar on the front bumper and stop there. The gap is behind the machine: a rear-facing light has to work on the driver following you, not on the trail ahead. Dust is the main reason. On a dry trail the vehicle behind sits in a cloud, and standard tail lamps vanish into it at 20 or 30 feet. A bar at cage height with a strobe or scroll pattern stays visible through that cloud, which keeps a group together and stops a following driver from closing too fast. The automatic functions do the quiet work. Brake, reverse and turn signals wired to their own triggers mean the bar behaves like a tail light when nobody is thinking about it, and the white output lights the ground behind the machine when you are backing into a trailer or turning around on a shelf road. A led light bar for trucks does a similar job on a road pickup, but a tailgate-mounted one sits low, under the gate. This one mounts at roughly the height of the driver behind you, which is where the light needs to be to read in dust and at distance. Durability is part of safety as well. For a utv led light bar used in convoys, that consistency matters more than a peak-output figure on a box.

JOPOWER 36 inch LED Rear Strobe LED Chase Light Bar for ATV UTV Offroad

Product Overview

The 36-inch rear strobe chase bar is the light that faces backwards. A front bar works the trail ahead; this one works on the vehicles behind you and on the driver in them. Running light, brake, reverse and turn signal sit in one 36-inch housing, and on top of that you get strobe, scroll and flash patterns for night running, dust and race checkpoints. It suits UTVs, side-by-sides, rails, buggies, Jeeps, ATVs and pickups prepared for loose ground, along with the shops, dealers, fleets and off road led light bar suppliers that keep those machines running. What separates this bar from a plain off road led light bar is the programming. The light is suited to off-road events, convoy operations and utility vehicle safety, where multi-color strobe and chase patterns help teams stay visible in dust, rain and low light.

JOPOWER 36 inch LED Rear Strobe LED Chase Light Bar for ATV UTV Offroad

Housing, Lens & Sealing

Everything structural sits behind a smooth face. There is no exterior hardware to snag on branches, no bolt heads standing proud of the housing and nothing for mud to pack into — the bar reads as a slim linear strip with a clear segmented lens between angled black end caps. Because we produce these ourselves as led light bar manufacturers, the housing is one high-grade aluminum alloy extrusion with the heat sink formed into it, so heat leaves the LEDs through the body instead of soaking the lens. A pressure-equalizing vent lets the air inside expand and contract with temperature without pulling moisture past the seals, and integrated thermal management covers the running range from −40 °F to 158 °F. The assembly is referenced to SAE J575 for shock and vibration — the standard that matters when a bar is bolted to a cage on stiff suspension and a washboard trail. Aluminum rather than coated steel is also what keeps the finish alive through winter salt and coastal air, while the high-impact polycarbonate lens is chosen for the stones that come off a rear tire at speed.

Mounting & Installation

  1. Choose the mount first: adjustable tube mounts clamp a round roll cage, while 15° horizontal brackets are for a flat rear panel. Flat-panel installs — many led light bar for trucks and Jeep builds — sit better on the horizontal bracket because the bar ends up parallel to the ground rather than following the cage angle.
  2. Dry-fit the bar and check the height. Aim for roughly the eye level of a driver sitting behind you; too low and the bar disappears behind a bumper or a spare tire.
  3. Bolt the brackets to the chosen surface and recheck that the face of the bar is clear of cage tubes and bodywork.
  4. Route the lead away from hot or moving parts, toward the switch or control point you plan to use.
  5. Connect the trigger inputs to the functions you want them to follow — running, brake, reverse, turn or a manual switch. On a led light bar for atv installs the usual set-up is a running light plus one manual auxiliary for the strobe.
  6. Assign a mode to each trigger from the 27 pre-programmed options.
  7. Test every function with the engine running, then check the fasteners again after the first rough ride, since brackets settle on new installations.
  8. Professional installation is strongly recommended where the bar is tied into brake, reverse and turn circuits.
JOPOWER 36 inch LED Rear Strobe LED Chase Light Bar for ATV UTV Offroad

Vehicle & Voltage Compatibility

  • A 12 V vehicle sits inside the operating window. A led light bar for atv runs on 9–16 VDC, so an ordinary 12 V system charging at roughly 13.8–14.4 V stays well inside that range, even with the engine running and accessories on.
  • A 24 V machine does not. A 24 V battery bank charges closer to 28–29 V, which is above the 16 V ceiling. The bar has to be fed from a DC-DC step-down converter or from a 12 V accessory circuit already on the machine — it cannot be wired straight to the battery.
  • Step down the trigger feeds as well. On a 24 V chassis the brake, reverse and turn circuits carry 24 V too, and the four trigger inputs expect a 12 V signal. Converting only the main power leaves the trigger side exposed, so plan the converter to serve both the supply and whatever signals the triggers follow.
  • Size the converter on continuous rating. Match it to the bar's running load with headroom, check the continuous figure rather than the peak, fuse the feed at the battery end, and mount the converter in a dry, protected spot away from heat and moving parts. Measure the tube diameter or the flat area before you order either set.
  • Standardise converters across a mixed fleet. If some machines are 12 V and others 24 V, off road led light bar suppliers should keep one converter part number so nobody connects a bar directly to the wrong battery, and mark the 24 V vehicles at the connection point.
  • Confirm the details before the order ships. Tell us the machine make and model, whether the 24 V figure is the battery nominal voltage or a reading taken at the terminals with the engine running, and what else shares that circuit. That is enough for us to confirm the right arrangement rather than leave the installer to work it out on site.

Modes, Triggers & Control

Control is the reason to pick this bar over a simple tail light. Twenty-seven modes come pre-programmed, covering the patterns crews actually use: steady running light, brake, reverse and turn signal, plus strobe, scroll and flash effects for dust, night running and checkpoints.

Those modes sit behind four trigger inputs — one running and three auxiliary. Each input takes its own choice from the 27, or a pattern built on top of them, which is where the 300,000-plus configuration figure comes from. In practice a machine can show a plain red running light on the road, an amber strobe in dust, a blue flash at a checkpoint and a white reverse light when reverse is engaged, all without touching the bar between uses.

Nothing needs a laptop or an app at the vehicle. The modes are loaded by us as led light bar manufacturers before the bar ships, and assignments are made through the trigger inputs, so the installer's job is deciding what each input should follow: the brake circuit, the reverse circuit, a turn signal, a dash switch or a vehicle control unit.

That flexibility is what makes a utv led light bar worth wiring into the loom rather than switching from the dash. If the machine already runs an auxiliary fuse block or a switch panel, the triggers can be fed from it, and the bar's electronics hold steady anywhere between 9 and 16 VDC.

Decide the assignments before the panels go back on. Changing one later takes a minute, but reaching the wiring on a finished cage usually does not.

Night convoys. An off road led light bar on the front makes you the one who can see; the light on the back makes you the one who gets seen. With riders stacked up in each other's dust, a strobing amber bar gives the machine behind a fixed point to follow. Hitching, reversing and loading. The white output on reverse is the small feature owners end up using most — backing a trailer onto a hitch in the dark, reversing off a ramp, or turning around on a narrow shelf road. It is the same job a led tailgate light bar does on a pickup, moved up to cage height where a bed or a spare tire cannot block it. Worksites and yards. Loaders, site trucks and side-by-sides moving around a half-lit yard need to be seen from behind as much as from the front. A steady amber or a slow flash reads clearly to a machine operator looking in a mirror. Race weekends and checkpoints. The same bar carries whichever color the series asks for, set on its own trigger, so the race pattern and the road pattern do not compete. Between the trails. Running light on, strobe off, one trigger change. That is what keeps the bar useful on the drive to the trailhead rather than a switch you only touch twice a season.

JOPOWER 36 inch LED Rear Strobe LED Chase Light Bar for ATV UTV Offroad

Industry Applications

  • Dealers and resellers. A rear bar is a steady repeat sale because it fits almost every side-by-side on the lot. Dealers and off road led light bar suppliers can hold one length and one mount type and cover most of their customers.
  • Install and upfit shops. One footprint, four signals and two bracket options shorten the wiring job and the number of parts kept on the shelf.
  • Rental, tour and excursion fleets. Group rides depend on vehicles being visible to each other; a strobing rear bar at cage height is the cheapest way to keep a convoy accounted for.
  • Race teams and event organizers. Multi-color strobe signaling is what technical inspection asks for, and separate triggers mean the bar can be switched back to road use afterwards.
  • Farm, ranch, mine and construction sites. Amber warnings on slow-moving utility vehicles, with a sealed housing that survives washdown and dust.

Race Series Signaling

  1. Check what the series asks for. Most off-road series that use rear strobes specify blue, amber, green or red for particular classes, and some specify the pattern as well as the color.
  2. Match the color and pattern to one of the 27 pre-programmed modes before you touch the wiring.
  3. Assign that mode to an auxiliary trigger, so the race setting is one input away instead of a reprogramming session in the paddock.
  4. Keep the running light on its own trigger. The bar then works as a normal tail light on the drive to the course and switches to the race pattern at inspection.
  5. Wire the trigger to whichever control the vehicle uses — dash switch, relay or control unit — and test the pattern at the height and angle the bar will actually run at. On a utv led light bar this takes minutes rather than a workshop visit.
  6. Set the second and third auxiliary triggers for anything else the weekend needs: a work pattern for the pits, a flash for a warning marker, a steady amber for a slow vehicle.
  7. The same routine works on a led light bar for trucks used as a course or sweep vehicle, where a distinct color tells competitors that a marshal is ahead.
JOPOWER 36 inch LED Rear Strobe LED Chase Light Bar for ATV UTV Offroad

Specifications

SpecificationDetail
Length36 in
Input voltage9–16 VDC
Pre-programmed modes27
LED colorsRed, white, blue, green, amber
Trigger inputsRunning plus three auxiliary
Possible configurationsOver 300,000
Ingress protectionIP68 (dust and water)
HousingHigh-grade aluminum alloy with integrated heat sink
LensHigh-impact polycarbonate
Shock and vibrationSAE J575 reference
Operating temperature−40 °F to 158 °F
Electrical protectionOver/under voltage and reverse polarity
Wiring lead13 in
MountingAdjustable tube mounts (1.5–2 in cage) or 15° horizontal brackets

Ordering & Delivery

Tell us four things and the order moves quickly: the vehicle the bar is going on, which mount you want (adjustable tube mounts or 15° horizontal brackets), what each trigger should follow, and whether the bar ships unbranded or with your logo and packaging.

Stock configurations go out on 7-day fast shipping. A custom led light bar run — your logo on the housing, your packaging, an adjusted size spec — follows a production schedule that we confirm with you at the time of order, and the same applies to mixed orders where part of the quantity is branded and part is not.

Mixed cartons are common so one shelf can carry more than one variant; tell us how you want the cartons split and we will pack to that.

If you are still deciding between this bar and a simpler rear light, send the vehicle details and the functions you need to cover, and we will come back with a mount recommendation, a trigger plan, a price and a ship date. For anything not listed as available, ask and we will confirm current stock.

JOPOWER 36 inch LED Rear Strobe LED Chase Light Bar for ATV UTV Offroad

Scale & Supply Capability

JOPOWER is the brand of our own factory in Dongguan, China, founded in 2010 and run by a team of 20–30 people with 15 years of vehicle lighting production behind them. We add 5–10 new styles every month, hold EU, CE, RoHS and US DOT certification, and put every unit through three full inspections before it leaves us. Because the designs are developed in-house, we can tailor specification, style, size, color, logo and packaging, and items in stock ship in as little as 7 days.

FAQ

What can be customized on this rear chase bar?

Size, color mix, logo and packaging are all open to customization. A dealer can take the standard 36-inch bar and turn it into a custom led light bar for their own shelf — own logo on the housing, own box, an adjusted size spec for a particular build — while the electronics stay the same. Send the artwork and the spec you need and we will confirm what is practical before the run starts.

Will this bar fit an ATV as well as a UTV?

The mount decides that, not the vehicle badge. The adjustable tube mounts cover a round roll cage, which takes in most side-by-sides and the cages used on led light bar for atv builds; where there is no round tube to clamp, the 15° horizontal brackets bolt to a flat rear panel instead. Measure the tube diameter and the flat area you have, and we will confirm the right bracket set.

How is this different from a led tailgate light bar?

A led tailgate light bar usually mounts under the gate and runs a fixed set of functions. This one mounts on the cage or a flat rear panel at about the height of the driver behind you, and it adds 27 selectable modes and four triggers on top of running, brake, reverse and turn. If you need strobe or chase patterns for dust, convoys or a race series, this is the part that does it.

What keeps the bar working through dust, water and vibration?

The housing is a high-grade aluminum alloy with an integrated heat sink, the lens is high-impact polycarbonate, and the assembly is sealed to IP68 for dust and water ingress. Shock and vibration are referenced to SAE J575, and a pressure-equalizing vent lets the housing breathe without drawing moisture in. That combination is what lets the bar stay on the vehicle through mud, spray and washboard instead of being swapped out each season.

Can each trigger run a different mode?

Yes. There are four trigger inputs — one running and three auxiliary — and each takes its own choice from the 27 pre-programmed modes, or a pattern built on top of them. That is where the 300,000-plus configuration figure comes from, and it is why one bar can serve as a road running light, a dust strobe and a checkpoint flasher without being reprogrammed between uses. We load the modes as led light bar manufacturers before the bar ships; the assignments are yours to set on the vehicle.

What comes in the box, and what should I plan for?

Each kit includes the 36-inch bar, the bracket set you order (adjustable tube mounts or 15° horizontal brackets) and a 13 inch lead for custom wiring. Switches, relays and the length of cable run to your control point belong to the vehicle installation rather than the kit, so plan them with your installer and allow time for that part of the job before the bar goes on.

Will it run on a 24 V machine?

Not directly. The bar is built for a nominal 12 V supply, so a 24 V machine needs a DC-DC step-down converter or a 12 V accessory circuit. Before ordering, tell us the machine make and model, whether 24 V is the battery nominal voltage or the charging voltage you measured, and what else shares that circuit. We will confirm the right approach rather than leave you to guess.

Size the converter for the bar's running load with some headroom, and check its continuous rating rather than its peak rating; if you are unsure of the draw, ask us for the figure to match. Fit the converter in a dry, protected spot, fuse the feed at the battery end, and keep the ground clean and tight. Use a multimeter at the connection point with the machine running to catch charging voltage and any spikes before the bar is connected. If your fleet mixes 12 V and 24 V machines, standardise on one converter part number so staff cannot connect a bar directly to the wrong battery. Machines with both voltages should use the 12 V side, and any converter must be rated for the circuit it feeds. If you plan to brand or package the bars for resale, confirm the 24 V arrangement with us at quotation stage so the kit and instructions match what your customers will install.
